Nagra IV-L. Mono Reel to Reel Tape Recorder [Images, Specifications and PDF Manual]

The Nagra IV-L is a self-contained high performance sound recorder of exceptional reliability. It will operate in any position. It can be powered either by internal batteries, or an external AC supply using an ATN power unit (not included). It is built to military and aeronautical standards, thus giving the recorder a reliability which has not been available heretofore in the electro-acoustical field. The Nagra IV-L is a single track monaural recorder that replaces the Nagra III PHO synchronous recorder.

Analog Dreams

Specifications

---

2 x microphone inputs that are 50 or 200 Ohm Dynamic
A Line Input on banana plugs or the 6 pin Tuchel ASS socket
1 & 2 high pass and 1&2 LAF Low Frequency Attenuation Filters
3 Taps speeds- 38, 19, 9.5cm/s (15-7.5-3.75ips)
60 Hz Strobe Roller, 1Khz
Reference Generator set a -8dB
Automatic Recording Limiter
Automatic and Manual Recording Level
Low Frequency Attenuation
Metering of Inputs, Battery, Pilot Level and Bias
7" tape spools with the lid open
Tape Bias and EQ is set for AGFA 468 or 368, Zonal 468 / 368 and BASF 468 or 368
